A seamless mowing experience
LM2236E-SP

55CM SELF-PROPELLED MOWER (KIT)

Featuring a wide cutting width, the LM2230E-SP is ideal for larger and sloping lawns and extremely versatile. You’ll have the option of mulching, or grass collection with the SELECT CUT interchangeable multi-blade cutting system. The new super composite, polycarbonate cutting deck is robust, lightweight and stable for prolonged use.

Read the full description below

Share this product

Product Specification

Voltage (V) 56
Deck Material PC/PBT
Deck Type Stamped
Cut Height Number 8
Blade Type Multi Blade
Collector Material Mesh w/ Anti-duct bag
IP Class IPX4
Sound Pressure Level LpA (dB(A)) 83
Sound Power Level LwA (dB(A)) 95
Uncertainty Sound Power (K) (dB(A)) 0.7
Uncertainty Sound Pressure (K) (dB(A)) 3
Guaranteed Sound Power Level LWA (dB(A)) 96
Vibration (M/S²) 1.35
Uncertainty Vibration (K) (M/S²) 1.5
LED Headlights Yes
Cutting Options 3-in-1
No Load Speed (rpm) 1: 2600 RPM 2: 2850RPM 3: 3000-3200 RPM
Deck Size (mm) 560
Blade Length (mm) 543
Collector Capacity (L) 85
Tool Weight (kg) 31.2
Tool Length(Unfold) (mm) 1601mm (@Lowest cutting height,Highest Handle Hei
Tool Width(Unfold) (mm) 596
Tool Height(Unfold) (mm) 1155
Tool Length(Fold) (mm) 952
Tool Width(Fold) (mm) 597
Tool Height(Fold) (mm) 409
Battery Port Single Port
Runtime 75min w/ 10.0Ah
Cutting Width (cm) 55
Motor Type Brushless
Show all

Full Product Description

The LM2230E-SP mower has a large 55cm cutting capacity which is perfect for effortless mowing of larger gardens. Self-propelled for your convenience, you can enjoy the benefits of the automatic variable cutting speed to help make your work a breeze.
The redesigned quick release aluminium folding handle lets you reduce the size of the mower for storage in a matter of seconds. You can also choose a side discharge accessory to quickly disperse your grass cuttings,
The kit comes complete with our 10Ah battery which can cut up to 2000sqm on a single charge. The 6 cut-height settings (between 25 to 100mm) mean you can get as close a cut as you wish, and you can choose to mulch or collect (80L collection bag) to get your desired finish.
Put petrol firmly in the past and enjoy a cleaner, quieter and safer mowing experience.

MOWER FEATURES

  • A MOWER FOR EVERY LAWN
    Our range offers a variety of key features and cutting capacities to suit any lawn
    01 / 10
    Next
  • High Torque, High-Efficiency Motor
    For operation in all conditions
    02 / 10
    Next
  • LED Headlights
    Work further into the day
    03 / 10
    Next
  • Quick Release Telescopic Handle
    For easy cleaning and compact storage
    04 / 10
    Next
  • Self-Propelled Motor
    Takes the strain out of mowing sloping ground
    05 / 10
    Next
  • Push Button Start
    Power up in seconds
    06 / 10
    Next
  • Adjustable Handle Height
    Easily adjusts to suit you and the job in hand
    07 / 10
    Next
  • Large Capacity Bag
    Collects more grass and requires emptying less frequently
    08 / 10
    Next
  • Large Diameter Wheels
    For easy motion on different terrains
    09 / 10
    Next
  • 7-Position Spring Loaded Deck Height Adjustment
    Easily set different grass cutting heights from 25-90mm
    10 / 10
    Start

Designed with your garden in mind

  • Small, tight spaces or close to trees
    For smaller spaces and improved precision around obstacles, mowers with a smaller cutting capacity are ideal.
  • Sloped Ground
    If you have a sloping garden, using a self-propelled mower takes the strain out of pushing the mower uphill.
  • Grass collection
    Rear discharge allows for quicker mowing through thick and long grass. Bag collection keeps lawns clear of any cuttings.
  • Easy to store
    The fold flat design makes cleaning and storage simple.

BATTERY FEATURES

  • A BATTERY LIKE NO OTHER
    Designed to maximise performance
    01 / 05
    Next
  • Exterior Mounted Battery
    Stays cool to deliver longer lasting power
    02 / 05
    Next
  • Power Management System
    Ensures the very best power, performance and run time
    03 / 05
    Next
  • Unique 'Keep Cool'™ Technology
    Maintains performance by preventing overheating
    04 / 05
    Next
  • Innovative Arc-Shaped Design
    Lowers temperature across the battery
    05 / 05
    Start
Challenge 2025
FOR A CLEANER, QUIETER AND SAFER FUTURE.
Visit Challenge 2025

Compare our mowers
